Used Dump Truck
1.Versatility
Perfectly suited for day-to-day challenges on construction and mining sites, handling a wide range of tasks.
2.Powerful Sinotruk Engine
Equipped with a reliable Sinotruk engine, delivering enhanced transport capacity for heavy loads.
3.Increased Safety
The truck is built with safety in mind, ensuring secure operations on demanding job sites.
4.Reliable Partner
Designed to be a dependable and efficient partner, helping you get the job done on time, every time.
5.Enhanced Efficiency
Offers improved performance, making it an ideal choice for boosting productivity on construction and mining sites.
Product Overview
The HOWO dump truck is designed to tackle the everyday challenges of construction and mining sites with unmatched versatility and reliability. Built to handle heavy-duty tasks, this truck features a robust Sinotruk engine that delivers powerful performance and increased transport capacity, ensuring you can move larger loads with ease. Whether you're dealing with rough terrain or demanding work conditions, the HOWO Dump Truck ensures superior safety and stability, making it a trusted partner for your operations.
Its durable construction and advanced engineering provide long-lasting performance, while its efficient fuel consumption helps to reduce operating costs. The truck is built to withstand the harshest environments, from construction sites to mining operations, offering a smooth and reliable operation no matter the job. With the HOWO Dump Truck, you gain more than just a vehicle—you get a reliable, efficient, and high-performance partner that enhances productivity and keeps your operations running smoothly.
Parameter
Truck Models | ZZ3257N3847C1 | |||
Truck Brand | SINOTRUK-HOWO | |||
Driving Style | LHD | |||
Dimension (LxWxH)(unloaded)(mm) | 8614x2496x3450 | |||
Cargo body size (L*W*H, mm)(mm) | 5800x2300x1500 | |||
Cargo thickness (mm) | Bottom: 8mm, Side: 6mm | |||
Lift type of Carriage | middle lifting | |||
Approaching angle/Departure angle | 19/26 | |||
Overhang (front/rear) (mm) | 1500/1739 | |||
Wheel base (mm) | 3825+1350 | |||
Max speed (km/h) | 75 | |||
Maximum gradeability (%) | 40 | |||
Minimum ground clearance (mm) | 314 | |||
Minimum turning circle (m) | 20 | |||
Curb weight (kg) | 12290 | |||
Loading Weight (kg) | 30000 | |||
Fuel tanker capacity (L) | 300 | |||
Fuel consumption (L/km) | 23L/100 km | |||
Clutch | Single-plate dry clutch Mast 430 mm | |||
Engine Model (Steyr technology, made in China) | Fuel type | Diesel | ||
Horse Power, max(kw/rpm) | ||||
Emission | EURO II | |||
Model | WD615, water-cooled, four strokes, 6 cylinders in line with water cooling, directly injection | |||
Bore | 126mm | |||
Stroke | 130mm | |||
Compression ratio | 29.8hp/l | |||
Specific fuel consumption | 195g/kwh | |||
Transmission | Model | HW19710, 10 forwards and 2 reverse | ||
Brake system | Service brake | Dual circuit compressed air brake | ||
Parking brake | spring energy, compressed air operating on rear wheels | |||
Auxiliary brake | Engine exhaust brake | |||
Steering system | Model | ZF8118 hydraulic steering with power assistance | ||
Front axle | HF9 | |||
Rear axle | HC16 | |||
Tyre | 12.002 | |||
Electrical system | Battery | 2X12V/165Ah | ||
Alternator | 28V-1500kw | |||
Starter | 7.5Kw/24V | |||
Cab | HW76cabin, one sleeper, with air conditioner | |||
Detail Display
The SINOTRUK HOWO 6x4 Dump Truck 371/375 HP is engineered to tackle the daily challenges faced on construction and mining sites with impressive versatility and reliability. Powered by a robust Sinotruk engine, this truck delivers 371/375 horsepower, providing excellent performance for heavy-duty tasks and increasing transport capacity. Whether you're hauling large loads of dirt, sand, or rocks, the HOWO Dump Truck ensures you can move materials with ease and efficiency.
Built for tough environments, the 6x4 drivetrain offers enhanced stability and traction, making it ideal for navigating rough, uneven terrain. Its durable frame and heavy-duty suspension system are designed to withstand the harsh conditions found on construction sites, mining operations, and other rugged environments.
Company Profile
Chengchuan Heavy Truck Co., Ltd., founded in August 2010, is located in Liangshan, Shandong, China — the largest used truck trading center in the world. The company employs nearly 300 people, including more than 200 professionals and technical specialists.
The company has a modern facility covering approximately 25,000 square meters and operates a top-tier domestic production line. It is capable of stocking, repairing, maintaining, and refurbishing up to 3,000 trucks of various types. Chengchuan offers a wide range of vehicles, such as tractor trucks, dump trucks, truck semitrailer mixers, and other specialized vehicles, along with spare parts from well-known brands like Sinotruk, Shacman, Volvo, Mercedes-Benz, and Beiben.
The company offers comprehensive one-stop services, including inspection, transportation, customs clearance, and after-sales support, to both domestic and international customers. Its sales and service network spans over 50 countries across Africa, Central Asia, and Southeast Asia, with sales reaching 100 million USD in 2024.
