Used Howo NX 8x4 Dump Truck
Power: Advanced engine technology ensures consistent performance under heavy loads and rugged terrain.
Load Capacity: Robust chassis design supports heavy-duty cargo requirements efficiently.
Fuel Efficiency: Smart energy management reduces fuel consumption without compromising power.
Durability: Corrosion-resistant materials and rigorous testing guarantee long-term reliability.
Howo dump truck matches the versatility required to overcome everyday challenges on construction and mining sites. Powered by the Sinotruk engine, it delivers increased transport capacity and heightened safety, proving to be a reliable and efficient workmate.
Truck Brand | SINOTRUK-HOWO NX | |
Driving Style | LHD | |
Dimension (LxWxH)(unloaded)(mm) | 10500x2496x3450 | |
Cargo body size (L*W*H, mm)(mm) | 7600x2300x1500 | |
Cargo thickness (mm) | Bottom: 8mm, Side: 6mm | |
Lift type of Carriage | middle lifting | |
Approaching angle/Departure angle | 19/26 | |
Overhang (front/rear) (mm) | 1500/1739 | |
Wheel base (mm) | 3825+1350 | |
Max speed (km/h) | 75 | |
Maximum gradeability (%) | 40 | |
Minimum ground clearance (mm) | 314 | |
Minimum turning circle (m) | 20 | |
Curb weight (kg) | 12290 | |
Loading Weight (kg) | 30000 | |
Fuel tanker capacity (L) | 300 | |
Fuel consumption (L/km) | 23L/100 km | |
Clutch | Single-plate dry clutch 430mm | |
Engine Model (Steyr technology, made in China) | Fuel type | Diesel |
Horse Power, max(kw/rpm) | ||
Emission | EURO II | |
Model | WD615, water-cooled, four strokes, 6 cylinders in line with water cooling, directly injection | |
Bore | 126mm | |
Stroke | 130mm | |
Compression ratio | 29.8hp/l | |
Specific fuel consumption | 195g/kwh | |
Transmission | Model | HW19710, 10 forwards and 2 reverse |
Brake system | Service brake | Dual circuit compressed air brake |
Parking brake | spring energy, compressed air operating on rear wheels | |
Auxiliary brake | Engine exhaust brake | |
Steering system | Model | ZF8118 hydraulic steering with power assistance |
Front axle | HF9 | |
Rear axle | HC16 | |
Tyre | 12.002 | |
Electrical system | Battery | 2X12V/165Ah |
Alternator | 28V-1500kw | |
Starter | 7.5Kw/24V | |
Shandong Camel Truck How to Refurbish Trucks
At Shandong Camel Truck Co., Ltd, we reengineer pre-owned trucks into vehicles that
Mechanical Maintenance & Overhaul: We thoroughly recondition the engine, transmission, and axle, replacing fundamental parts like oil and filters.
Exterior Refresh: The truck’s body, chassis, cab, and rims are repainted to restore their fresh appeal.
Component Upgrades: We replace essential components—including the battery, fuel tank, circuits, and gas path—and rejuvenate the air conditioning system.
Cabin Refresh: The cabin is upgraded with new seating, a sleeper, dashboard, and interior upgrades.
Final Touch: A pre-shipment waxing is applied to achieve a polished finish.
Why Choose CAMEL TRUCK
Using advanced equipment,we perform extensive engine inspections
performance testing and provide a comprehensive test report, ensuring reliable long-term performance.
Timely delivery
CAMEL TRUCK has a wealth of shipping experience with leading shipping companies and freight forwarders, ensuring your products arrive safely and on schedule at the destination port.
