Efficient SINOTRUK HOWO Garbage Truck
25T capacity, 371HP, low 29L/100km fuel use
Perfect for urban waste collection
Product Details
Product Description
The SINOTRUK HOWO Packer Garbage Truck via CSCTRUCK is designed for environment friendly city waste collection. Featuring a sealed compartment, hydraulic system, and common controls, it ensures leak-proof compression, dumping, and wastewater contain-ment in a committed tank. Key elements are imported, turning in high-pressure performance, greatest sealing, handy operation, and stronger safety. Ideal for current waste management, it combines reliability, efficiency, and labor-saving automation for straight forward refuse handling.
Specification
| Model Number | HOWO Garbage Truck-Compressed type |
| Driving type | 6x4/4x2/8x4 |
| Rated Loading Weight(kg) | 10000 |
| Kerb Weight(kg) | 15000 |
| Total Mass(kg) | 25000 |
| Overall dimesion(L*W*H)mm | 9980*2500*3650 |
| Min. Turning Circle (m) | 21.6 |
| Max. Speed (Km/h) | 90 |
| Fuel Consumption(L/100km) | 29 |
| Engine | SINOTRUK Brand,WD615.47,EURO-2 |
| Horse Power(hp/r/min) | 371/2200 |
| Volume of the Body(m3) | 18.5 |
| Volume of the Filler(m3) | 2.5 |
| Time of one Loading Cycle(s) | <25 |
| Time of one Unloading Cycle(s) | <40 |
| Max Brake Crase Pressure(kgf) | >35000 |
| Transmission | HW19710, 10 forward and 2 reverse |
| Clutch | Dia.430mm, Hydraulically operating with air assitance |
| Front Axle | HF7 |
| Rear Axle | ST16 |
| Steering | ZF8098 |
| Brake | Dual circuit compressed air service bake, spring energy parking brake, engine exhaust auxiliary brake, ABS for option |
| Tyre | 12.00R20 Radial tyre |
